Electronics and PCB design — prototype and revision-ready

Schematic and PCB layout, revisions, DFM and prototype-ready manufacturing outputs (Gerbers, BOM, notes).

service
01 / What this service is

What this service is

We design and revise electronics for prototypes and products, focusing on deliverables that manufacturers can actually build.

Typical scope includes:

01

Schematic Design or Modification

02

PCB Layout — New or Revision

03

DFM Considerations & Iteration Support

04

Prototype-ready Manufacturing Output Pack

Scope confirmed during discovery — partial scope engagements available.

02 / Who it's for

Who it's for

Tap any row to see why.

Good fit if

You need a V1 prototype PCB for a new product idea

We scope around your concept stage — imperfect specs welcome. We help define what 'done' looks like before layout begins.

You need a revision to improve reliability, manufacturability, or assembly

Targeted revisions to existing designs — improving yield, reducing assembly complexity, or fixing field failures.

You want clear handover files (Gerbers / BOM / notes) and documentation

Every engagement ends with a manufacture-ready output pack your CM can act on without chasing you for clarification.

Not a fit if

Your project is a regulated medical device or manned aviation / aerospace

These domains require specialist compliance frameworks we don't cover. We'll tell you upfront rather than waste your time.

You need highly specialised autonomy R&D — not electronics design itself

Niche autonomy research beyond pragmatic drones or mechatronics positioning sits outside our current scope.

Not sure? Book a free 20-min call — we'll tell you honestly.

03 / Problems we solve

Problems we solve

Recognise any of these? Flip a card to see how we approach it.

Stability01

"Our prototype PCB is unstable or hard to assemble."

flip →
Our approach← back

We audit your existing design, identify root causes — layout, component choice, or thermal issues — and deliver a revised board that builds cleanly first time.

DFM02

"We need a revision that is easier to manufacture."

flip →
Our approach← back

DFM review against your target CM's capabilities — clearances, footprints, panelisation, and assembly constraints resolved before Gerbers are sent.

Integration03

"We need to integrate sensors, power, connectivity, and constraints."

flip →
Our approach← back

Full schematic scoping and layout for multi-domain boards — power rails, sensor interfaces, RF keep-outs, and constraint-driven routing handled together.

Handover04

"We need clean manufacturing outputs and clear documentation."

flip →
Our approach← back

Gerbers, BOM, pick-and-place, assembly notes, and a design summary — everything your CM needs to quote and build without chasing you for files.

Not sure if your problem fits? Book a free call

04 / Deliverables

What you receive

Depending on scope, deliverables can include the following. Hover any row to see detail.

Confirmed during scoping — not all apply to every engagement.

01

Schematic Files & Outputs

02

PCB Layout Files

03

Gerbers & Drill Files

04

BOM & Component Notes

05

Assembly Notes & Constraints

06

Revision Notes & Change Summary

07

Bring-up & Test Notes

All files are yours — no lock-in, no proprietary formats.

05 / Engagement modes

How we engage

Three structured paths — choose based on your current situation. Click any option to expand.

A

Common for SMEs

PCB Revision & Stabilisation

B

Common for founders

Prototype PCB for V1

C

If scope is unclear

Audit Sprint

Minimum engagement

Contact us for current availability and minimum project scope.

Get in touch →
06 / Tools & stack

Tools & stack

We work with mainstream PCB CAD tools and provide exchangeable outputs for supplier compatibility. Toolchain confirmed during discovery.

toolchain_01.config
0

Tools

0

Category

0

Priority

— Overview

Primary EDA tools for schematic capture and PCB layout — chosen to match your existing environment or CM requirements.

— Tooling

KiCad
Altium Designer
EasyEDA / JLCPCB
Eagle (legacy support)

Toolchain confirmed during discovery — always matched to your environment.

07 / Relevant work

Relevant work

Two examples of electronics design engagements — PCB stabilisation and V1 prototype builds.

67%

reduction in assembly failures

CASE — 02

PCB Stabilisation for IoT Sensor Module

— Problem

A hardware startup had a V2 board with persistent assembly failures and field reliability issues. CM was flagging the same defects across every batch.

— Outcome

Full DFM review and targeted layout revision. Footprint corrections, courtyard fixes, and trace rerouting around a thermal hotspot. New manufacturing pack delivered in two revision rounds.

— What we built

  • DFM audit report
  • Revised KiCad layout
  • Updated Gerbers & drill files
  • Assembly constraint notes

— Stack

KiCad 7Gerber 274-XCSV BOMLTspice thermal check
Placeholder — real case study in progressView case study →
V1

prototype built first pass

CASE — 03

V1 Prototype PCB for Wearable Device

— Problem

A founder needed a V1 prototype PCB for a wearable concept — no existing design, just a requirements brief and a target CM in mind.

— Outcome

Schematic design, multi-layer PCB layout, and a full manufacturing output pack. CM received Gerbers, BOM with LCSC references, and pick-and-place on first handover.

— What we built

  • Full schematic
  • 4-layer PCB layout
  • Gerbers + drill files
  • BOM with alternates
  • PnP + assembly notes

— Stack

Altium DesignerLCSC BOM refsODB++ outputPDF assembly drawing
Placeholder — real case study in progressView case study →

See all work

Full case study library across all service areas

View all work →
